Alloys made of monel have a high level of corrosion resistance. These nickel-based alloys come in a variety of grades and are sold in different markets. A Monel Pipe's ability to withstand corrosion makes it helpful in areas including chemical processing, naval engineering, and oil. Although the oil and gas industry is the main consumer of B165 Monel Alloy Seamless Pipe. Fossil fuels, including coal, petroleum, and natural gas, are used in the oil and gas business.
These fossil fuels contain hydrocarbons in their chemical composition. The ASME SB 165 Seamless Monel Pipe are subjected to exothermic processes that release carbon dioxide, water, and heat while processing hydrocarbons. Since heat is used in the processing of hydrocarbons, these reactions could corrode ordinary steel alloys and result in deterioration. However, the nickel-containing alloys used to create the ASTM B725 Monel Welded Pipe enhance the component's heat resistance.
The Monel Hexagonal Pipe also has some corrosion resistance capabilities due to the copper that is present in it. The Monel Hollow Pipe, a useful component in high pressure transmission of the oil and gas industry, is made from this alloy because its tensile strength is greater than several standard steel alloys. The Monel ERW Pipe benefits from its resistance to alkalis as well as its resistance to hydrofluoric acid and sulfuric acid. The alloy is malleable, making the production of monel drill pipe simple, similar to other alloys with considerable quantities of both nickel and copper.
compare Monel Seamless Pipe price with inconel pipe price list
Size | ½” to 6” NB Sch 10s, 40s, & 80s, 160s |
Wall Thickness | 0.1 - 60 mm |
Length |
|
Surface Finish | Cold Finish, Bright, Polished, Annealing, Pickling, or as per client requirements |
Standard | JIS, AISI, ASME, ASTM, AMS, GB, DIN, EN, GOST |
Manufacturing types | Seamless, Welded, ERW, EFW |
Manufacturing Shapes | Round, Square, Rectangle, Box Section |
Manufacturing Technology | Hot / Cold Formed |
Other Grades | SS 446 |
Inspection, Test Reports | EN 10204 3.1, Mill Test Certificates, PMI Test Reports, Chemical Reports, Mechanical Reports, NABL Approved Lab Reports, Visual Inspection Reports, Destructive and Non Destructive Test Reports, Third Party Inspection |
Technique | Cold Rolled Hot Rolled |
Description | Per Unit (INR) | Price in USD | Price in EURO | |||||
---|---|---|---|---|---|---|---|---|
Monel 400 Pipes 1 1/2 Sch 40 (Seamlessor Welded) (4 To 7 Mtr Long) | 14,785 | 200.43 | 165.37 | |||||
Monel 400 Pipes 1/4 Sch 40 (Seamless Orwelded) (4 To 7 Mtr Long) | 2,264 | 30.69 | 25.32 | |||||
Pipes Fittings & Flanges:nipple Pipes Type Seamless Size 1/2 Inch Length 6 Inch Connection Tbe Material Monel 400 Astm B16 | 2,173 | 29.46 | 24.30 | |||||
Nipple ,pipes Size:1/2length :6 connection:threaded Both Ends,sch-80s,grade:-unsno4400 Monel 400 Astm B165 | 1,767 | 23.95 | 19.76 | |||||
Seamless Pipes 4 Sch 80 X 1 Mtr (Monel 400) | 101,259 | 1372.68 | 1132.58 | |||||
Seamless Pipes 4 Sch 10 X 1 Mtr (Monel 400) | 38,735 | 525.10 | 433.25 | |||||
Nickel Alloy Pipes- Seamless Pipe 3 Sch40 X 1.3 Mtr (Monel 400) | 67,099 | 909.60 | 750.50 | |||||
Nipple, Pipes Type Seamless, Size 3/4 In,length 6 In, Connection Npt,material Monel 400 Astm B165, Rating Sch 80s, Grade | 4,134 | 56.04 | 46.24 | |||||
Monel 400 Pipes Asme Sb 165 Size : 10 Nb X Sch 20 | 170,614 | 2312.86 | 1908.31 | |||||
Nickel Alloy Pipes 1x Sch 80x6 Mtr Monel 400 Smls | 82,830 | 1122.85 | 926.45 | |||||
Monel 400 Pipes 1-1/2 X Sch 160 Smls | 102,931 | 1395.34 | 1151.28 | |||||
Nickel Alloy Pipes 3/8 Od X 0.049 Wt Monel 400 Smls | 1,688 | 22.88 | 18.88 |
The following welding techniques, such as gas bend welding, gas metal-curve welding, metal circular segment welding, and submerged arc, are used on Monel hexagonal pipes. The use of suitable filler metals is incorporated into the welding cycle for Monel ERW Pipe. Playing out a post-weld heat treatment is not necessary. Despite the fact that the Monel ERW pipe needs to be thoroughly cleaned once the composite is welded.
Monel Pipe OD mm |
Pipe WT mm |
in. |
Sch |
Kg/m |
---|---|---|---|---|
13.72 |
1.65 |
1/4 |
10S |
0.50 |
13.72 |
2.24 |
1/4 |
40S |
0.64 |
13.72 |
3.02 |
1/4 |
80S |
0.81 |
17.15 |
1.65 |
3/8 |
10S |
0.64 |
17.15 |
2.31 |
3/8 |
40S |
0.86 |
17.15 |
3.20 |
3/8 |
80S |
1.12 |
21.34 |
2.11 |
1/2 |
10S |
1.02 |
21.34 |
2.77 |
1/2 |
40S |
1.29 |
21.34 |
3.73 |
1/2 |
80S |
1.65 |
26.67 |
2.11 |
3/4 |
10S |
1.30 |
26.67 |
2.87 |
3/4 |
40S |
1.71 |
26.67 |
3.91 |
3/4 |
80S |
2.23 |
33.40 |
2.77 |
1 |
10S |
2.13 |
33.40 |
3.38 |
1 |
40S |
2.54 |
33.40 |
4.55 |
1 |
80S |
3.29 |
33.40 |
6.352) |
1 |
160 |
4.30 |
42.16 |
2.77 |
1¼ |
10S |
2.73 |
42.16 |
3.56 |
1¼ |
40S |
3.44 |
42.16 |
4.85 |
1¼ |
80S |
4.53 |
42.16 |
6.352) |
1¼ |
160 |
5.69 |
48.26 |
2.77 |
1½ |
10S |
3.16 |
48.26 |
3.68 |
1½ |
40S |
4.11 |
48.26 |
5.08 |
1½ |
80S |
5.49 |
60.33 |
2.77 |
2 |
10S |
3.99 |
60.33 |
3.91 |
2 |
40S |
5.52 |
60.33 |
5.54 |
2 |
80S |
7.60 |
60.33 |
8.742) |
2 |
160 |
11.29 |
73.03 |
3.05 |
2½ |
10S |
5.35 |
73.03 |
5.16 |
2½ |
40S |
8.77 |
73.03 |
7.01 |
2½ |
80S |
11.59 |
88.90 |
3.05 |
3 |
10S |
6.56 |
88.90 |
5.49 |
3 |
40S |
11.47 |
88.90 |
7.62 |
3 |
80S |
15.51 |
88.90 |
11.132) |
3 |
160 |
21.67 |
101.60 |
3.05 |
3½ |
10S |
7.53 |
101.60 |
5.74 |
3½ |
40S |
13.78 |
101.60 |
8.08 |
3½ |
80S |
18.92 |
114.30 |
3.05 |
4 |
10S |
8.50 |
114.30 |
6.02 |
4 |
40S |
16.32 |
114.30 |
8.56 |
4 |
80S |
22.67 |
114.30 |
13.492) |
4 |
160 |
34.05 |
141.30 |
6.55 |
5 |
40S |
22.10 |
141.30 |
9.53 |
5 |
80S |
31.44 |
141.30 |
15.882) |
5 |
160 |
49.87 |
168.28 |
3.4 |
6 |
10S |
14.04 |
168.28 |
7.11 |
6 |
40S |
28.69 |
168.28 |
10.97 |
6 |
80S |
43.21 |
168.28 |
14.27 |
6 |
120 |
54.75 |
168.28 |
18.262) |
6 |
160 |
68.59 |
219.08 |
8.18 |
8 |
40S |
43.20 |
219.08 |
12.7 |
8 |
80S |
65.63 |
219.08 |
18.23 |
8 |
120 |
91.30 |
219.08 |
23.012) |
8 |
160 |
112.97 |
Monel® 400 Seamless or Welded Pipe | Thickness | Nominal Diameter (Standard) | Nominal Diameter (Metric) |
---|---|---|---|
1 Inch Sch. 10 | Sch. 10 | 1 inches | 25 mm |
1 Inch Sch. 160 | Sch. 160 | 1 inches | 25 mm |
1 Inch Sch. 40 | Sch. 40 | 1 inches | 25 mm |
1 Inch Sch. 5 | Sch. 5 | 1 inches | 25 mm |
1 Inch Sch. 80 | Sch. 80 | 1 inches | 25 mm |
1 Inch Sch. XXH | Sch. XXH | 1 inches | 25 mm |
1 1/2 Inch Sch. 10 | Sch. 10 | 1 1/2 inches | 40 mm |
1 1/2 Inch Sch. 160 | Sch. 160 | 1 1/2 inches | 40 mm |
1 1/2 Inch Sch. 40 | Sch. 40 | 1 1/2 inches | 40 mm |
1 1/2 Inch Sch. 80 | Sch. 80 | 1 1/2 inches | 40 mm |
1 1/2 Inch Sch. XXH | Sch. XXH | 1 1/2 inches | 40 mm |
1 1/4 Inch Sch. 10 | Sch. 10 | 1 1/4 inches | 32 mm |
1 1/4 Inch Sch. 160 | Sch. 160 | 1 1/4 inches | 23 mm |
1 1/4 Inch Sch. 40 | Sch. 40 | 1 1/4 inches | 32 mm |
1 1/4 Inch Sch. 80 | Sch. 80 | 1 1/4 inches | 32 mm |
1 1/4 Inch Sch. XXH | Sch. XXH | 1 1/4 inches | 23 mm |
1/2 Inch Sch. 10 | Sch. 10 | 1/2 inches | 15 mm |
1/2 Inch Sch. 160 | Sch. 160 | 1/2 inches | 15 mm |
1/2 Inch Sch. 40 | Sch. 40 | 1/2 inches | 15 mm |
1/2 Inch Sch. 80 | Sch. 80 | 1/2 inches | 15 mm |
1/2 Inch Sch. XXH | Sch. XXH | 1/2 inches | 15 mm |
1/4 Inch Sch. 10 | Sch. 10 | 1/4 inches | 8 mm |
1/4 Inch Sch. 40 | Sch. 40 | 1/4 inches | 8 mm |
1/4 Inch Sch. 80 | Sch. 80 | 1/4 inches | 8 mm |
1/8 Inch Sch. 40 | Sch. 40 | 1/8 inches | 6 mm |
Monel
Alloys made of monel have a high level of corrosion resistance. These nickel-based alloys come in a variety of grades and are sold in different markets. A Monel Pipe's ability to withstand corrosion makes it helpful in areas including chemical processing, naval engineering, and oil.
Monel Alloys Compositions (Percentages)
Trade Name | ASTM/AISI
Alloy Type |
UNS | %Cu | %Al | %Ti | %Fe | %Mn | %Si | %Ni |
---|---|---|---|---|---|---|---|---|---|
400 | B 127, B 164 | N04400 | 28-34 | 2.5 Max | 2.0 Max | 0.5 Max | 63 Min | ||
401 | N04401 | 28-34 | 2.5 Max | 2.0 Max | 63 Min | ||||
404 | N04404 | Rem | 0.05 Max | 0.5 Max | 0.1 Max | 0.1 Max | 52-57 | ||
K-500 | B 865 | N05500 | 27-33 | 2.3-3.15 | 0.35-0.85 | 2.0 Max | 1.5 Max | 0.5 Max | 63 Min |
405 | B 164 |
Inconel
Nickel and chromium make up the majority of the chemistry of inconel alloys, which are superalloys. The microstructure of these alloys is austenitic, which makes it simple to manufacture Inconel Pipe. Austenite alloys are thought to be very malleable and very ductile.
Inconel Composition
Inconel | Element (% By Mass) | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Ni | Cr | Fe | Mo | Nb | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
600 | 72.0 | 14.0–17.0 | 6.0–10.0 | 1.0 | 0.5 | 0.5 | 0.15 | 0.015 | |||||||
617 | 44.2–56.0 | 20.0–24.0 | 3.0 | 8.0–10.0 | 10.0–15.0 | 0.5 | 0.5 | 0.8–1.5 | 0.6 | 0.5 | 0.15 | 0.015 | 0.015 | 0.006 | |
625 | 58.0 | 20.0–23.0 | 5.0 | 8.0–10.0 | 3.15–4.15 | 1.0 | 0.5 | 0.4 | 0.4 | 0.5 | 0.1 | 0.015 | 0.015 | ||
690 | 59.5 | 30 | 9.2 | 0.35 | 0.01 | 0.02 | 0.35 | 0.019 | 0.003 | ||||||
718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.5 | 1.0 | 0.35 | 0.2–0.8 | 0.65–1.15 | 0.3 | 0.35 | 0.08 | 0.015 | 0.015 | 0.006 |
X-750 | 70.0 | 14.0–17.0 | 5.0–9.0 | 0.7–1.2 | 1.0 | 1.0 | 0.5 | 0.4–1.0 | 2.25–2.75 | 0.5 | 0.08 | 0.01 |
Types | Out diameter | Wall thickness | Length |
---|---|---|---|
NB Sizes (in stock) | 1/8” ~ 8” | SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 | Upto 6 Meters |
monel 400 Seamless Pipe (Custom Sizes) | 5.0mm ~ 203.2mm | As per requirement | Upto 6 Meters |
monel 400 Welded Pipe (in Stock + Custom Sizes) | 5.0mm ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
Specifications: |
ASTM B165, ASTM B829, ASTM B775, ASTM B725, ASTM B163, ASTM B730, ASTM B751,ams 4574 |
International Specifications: |
